MKTI - Modular contact block, momentary

Series

Kontaktgeber MK...

Contact type

1NO

Switching function

Momentary function

Connection

Screw connection

Illumination

Degree of protection front

IP20

Operating temperature

-40°C ... 70°C ohne Beleuchtung
-40°C ... 70°C bei LED-Beleuchtung

Rated operating voltage

240 V AC
480 V AC
24 V DC
60 V DC
125 V DC
250 V DC

Rated operating current

3 A AC
1.5 A AC
2 A DC
1 A DC
0.4 A DC
0.2 A DC

Mechanical life

> 1,000,000 switching cycles
50,000 switching cycles emergency-stop

Electrical life

1,000,000 switching cycles

Approvals

CE, UKCA

Material

PA66
